Discontinued - 7 watt LED Downlight Retrofit; 3" Baffle; 3000K; Miniature 2 Pin Round base; 12 (40JR50W)
$74.60
Call For Price
Enlarge Image
Add to Cart
Description:
Discontinued - 7 watt LED Downlight Retrofit; 3" Baffle; 3000K; Miniature 2 Pin Round base; 12 volts; Dimmable
Availability:
  • Manufacturer has 48 items available.
  • This Item has been Discontinued. Please verify product pricing and availability with vendor prior to submitting any orders.
Required Components:

Optional Accessory:

Dimensions:
right arrow Height: 3.00"
right arrow Width: 4.00"
Additional Details:
right arrow Finish: White
right arrow Category: Recessed
right arrow Sub Category: Retrofits
right arrow Style: Contemporary
right arrow Additional Info: The dimming control will depend on the Driver or transformer that is been used, as an example if a magnetic Tramformer is being used it will require an LV dimmer (for example Lutron DVLV-600P-WH) if an Electronic transformer is being used it will require a
right arrow Avg Rated Hours: 35000
right arrow Bulb Shape1: Integrated LED
right arrow Bulb Type1: LED
right arrow Color Temperature: Warm White
right arrow Diameter: 4
right arrow Dimmable: Yes-Dimmable
right arrow Each Height: 5.07
right arrow Each Length: 4.92
right arrow Each Width: 3.54
right arrow Lumens: 401L
right arrow Tariff Code: 8539.50.0091
right arrow Warranty: 3 Year Limited - Fixtures
right arrow Amps: 0.583A
right arrow ANSI Base: Bi-Pin Adapter
right arrow BAA Compliant: No
right arrow Beam Angle: 90
right arrow CA Prop-65: Lead
right arrow Can Size: 3 in.
right arrow CCT Selectable: No
right arrow CEC: Exempt - Base Not Regulated
right arrow CEC Terse: Lawful for sale in California
right arrow CEC Web Text: Lawful for sale
right arrow Connection: Direct Wired
right arrow Country Of Origin: China
right arrow CRI: 90+
right arrow Dimmable Down To: 100 to 20 percent
right arrow Dimming Type: Forward Phase or Reverse Phase or Phase Selectable or Triac
right arrow Each Cube: 0.0511
right arrow Each Quantity: 1
right arrow Efficacy: 57.29 LPW
right arrow FCC Compliant: Yes
right arrow Finish Family: White
right arrow Fixture shape: Round
right arrow Incandescent Equivalent: 50W
right arrow Indoor Outdoor: Indoor
right arrow JA8 Compliant: No
right arrow Mounting Procedure: Ceiling
right arrow Operating Temp: -20C (-4F) to +45C (+113F)
right arrow Order In Multiples Of: 1
right arrow Pack Type: Box
right arrow Quantity In Pack: 1
right arrow Replaceable Light Source: No
right arrow RoHS Compliant: Yes
right arrow SDS class: LED_Fixture
right arrow Short Description: 7WLED/RDL/3"BFL/12V 90CRI 3K
right arrow Temperature (CCT): 3000K
right arrow Title 20 Compliant: Exempt
right arrow Title 24 Compliant: No
right arrow Trim Color: White
right arrow Wattage Selectable: No
right arrow Standard Category: Recessed Ltg.
right arrow Standard Subcategory: Other Recessed Ltg.
right arrow Standard Finish: White
right arrow Standard Style: Contemporary
right arrow Standard Option: LED , Prop 65 prop65.png
Internal #:
40JR50W
